SYS-1029GQ-TRT-NEBS

Key Applications
• Edge Computing
• Micro Data Center
• AI/ML, Deep Learning Training and Inference
• Virtualization
• Cloud Computing


Key Features
1. NEBS Level 3 certified
2. Dual Socket P (LGA 3647) support
    2nd Gen Intel® Xeon® Scalable
    processors (Cascade Lake/Skylake)‡
3. 12 DIMMs; up to 3TB 3DS ECC
    DDR4-2933MHz† RDIMM/LRDIMM,
    Supports Intel® Optane™ DCPMM††
4. 4 PCI-E 3.0 x16 (FHFL) slots,
    2 PCI-E 3.0 x16 (LP) slots
5. 2 Hot-swap 2.5" SAS/SATA
    drive bays, 2 Internal 2.5" SATA drive bays
6. Support 1x M.2 2242/2260/2280,
    Support M.2 SATA and NVMe
7. 2x 10GBase-T LAN ports via Intel X540
8. 9 Heavy duty 4cm counter-rotating
    fans with air shroud & optimal fan
    speed control
9. 2000W Redundant Power Supplies
    Titanium Level (96%)

Specifications
Product SKUs
SYS-1029GQ-TRT-NEBS
  • SuperServer 1029GQ-TRT-NEBS

Motherboard

Super X11DGQ

Processor
CPU
  • Dual Socket P (LGA 3647)
  • 2nd Gen Intel® Xeon® Scalable Processors and Intel® Xeon® Scalable Processors‡,
    3 UPI up to 10.4GT/s
  • Support CPU TDP up to 165W
Cores
  • Up to 28 Cores
Note ‡ BIOS version 3.2 or above is required to support 2nd Gen Intel® Xeon® Scalable processors (codenamed Cascade Lake-R).

Extended thermal solutions may be required to support CPUs higher than 165W TDP, please contact Supermicro Technical Support for additional information.

GPU
Supported GPUs
  • 4 Double-Width/Single-Width PCI-E 3.0 x16 Card (Full Height Full Length)
  • NVIDIA V100, V100S
  • Compatible GPU list
CPU-GPU Interconnect
  • PCI-E Gen 4 x16 Direct Connect CPU-GPU Dual-Root

System Memory
Memory Capacity
  • 12 DIMM slots
  • Up to 3TB 3DS ECC DDR4-2933MHz† RDIMM/LRDIMM
  • Supports Intel® Optane™ DCPMM††
Memory Type
  • 2933†/2666/2400/2133MHz ECC DDR4 RDIMM/LRDIMM
Note † 2933MHz in two DIMMs per channel can be achieved by using memory purchased from Supermicro
†† Cascade Lake only. Contact your Supermicro sales rep for more info.

On-Board Devices
Chipset
  • Intel® C621 chipset
SATA
  • SATA3 (6Gbps) with RAID 0, 1, 5, 10
Network Connectivity
  • Intel® X540 Dual Port 10GBase-T
  • Virtual Machine Device Queues reduce I/O overhead
  • Supports 10GBASE-T, 100BASE-TX, and 1000BASE-T, RJ45 output
IPMI
  • Support for Intelligent Platform Management Interface v.2.0
  • IPMI 2.0 with virtual media over LAN and KVM-over-LAN support
Graphics
  • ASPEED AST2500 BMC

Input / Output
SATA
  • 4 SATA3 (6Gbps) ports
LAN
  • 2 RJ45 10GBase-T ports
  • 1 RJ45 Dedicated IPMI LAN port
USB
  • 2 USB 3.0 ports (rear)
Video
  • 1 VGA port
Serial Header
  • 1 Fast UART 16550 header

System BIOS
BIOS Type
  • AMI 32Mb SPI Flash ROM

Management
Software
Power Configurations
  • ACPI / APM Power Management

PC Health Monitoring
CPU
  • Monitors for CPU Cores, Chipset Voltages, Memory.
  • 4+1 Phase-switching voltage regulator
FAN
  • Fans with tachometer monitoring
  • Status monitor for speed control
  • Pulse Width Modulated (PWM) fan connectors
Temperature
  • Monitoring for CPU and chassis environment
  • Thermal Control for fan connectors
Chassis
Form Factor
  • 1U Rackmount
Model
  • CSE-118GQETS-R2K05P2

Dimensions and Weight
Height
  • 1.7" (43mm)
Width
  • 17.2" (437mm)
Depth
  • 35.2" (894mm)
  • 39.3" (997mm) with rails
Package
  • 24" (H) x 8" (W) x 46" (D)
Weight
  • Net Weight: 45 lbs (20.4 kg)
  • Gross Weight: 58 lbs (26.31 kg)
Available Color
  • Black

Front Panel
Buttons
  • Power On/Off button
  • System Reset button
LEDs
  • Power LED
  • Hard drive activity LED
  • Network activity LEDs
  • System Overheat LED / Fan fail LED /
    UID LED

Expansion Slots
PCI-Express
  • 4 PCI-E 3.0 x16 (FHFL) slots - supporting up to 4 GPUs
  • 2 PCI-E 3.0 x16 (LP) slots

Drive Bays
Hot-swap
  • 2 Hot-swap 2.5" SAS/SATA drive bays
Fixed
  • 2 Internal 2.5" SATA drive bays
M.2
  • Support 1x M.2 2242/2260/2280
  • Support M.2 SATA and NVMe

System Cooling
Fans
  • 9 Heavy duty 4cm counter-rotating fans with air shroud & optimal fan speed control

Power Supply
2000W Redundant Power Supplies with PMBus
Total Output Power
  • 1000W: 100 – 120Vac
  • 1800W: 200 – 220Vac
  • 1980W: 220 – 230Vac
  • 2000W: 230 – 240Vac
  • 2000W: 200 – 240Vac (UL/CUL only)
Dimension
(W x H x L)
  • 73.5 x 40 x 265 mm
Input
  • 100-120Vac / 12.5-9.5A / 50-60Hz
  • 200-220Vac / 10-9.5A / 50-60Hz
  • 220-230Vac / 10-9.8A / 50-60Hz
  • 230-240Vac / 10-9.8A / 50-60Hz
  • 200-240Vac / 11.8-9.8A / 50-60Hz (UL/cUL only)
+12V
  • Max: 83.3A / Min: 0A (100-120Vac)
  • Max: 150A / Min: 0A (200-220Vac)
  • Max: 165A / Min: 0A (220-230Vac)
  • Max: 166.7A / Min: 0A (230-240Vac)
  • Max: 166.7A / Min: 0A (200-240Vac) (UL/cUL only)
12Vsb
  • Max: 2.1A / Min: 0A
Output Type
  • 25 Pairs Gold Finger Connector
Certification   Titanium Level
  [ Test Report ]

Operating Environment
RoHS
  • RoHS Compliant
Environmental Spec.
  • Operating Temperature:
       10°C ~ 35°C (50°F ~ 95°F)
  • Non-operating Temperature:
       -40°C to 60°C (-40°F to 140°F)
  • Operating Relative Humidity:
       8% to 90% (non-condensing)
  • Non-operating Relative Humidity:
       5% to 95% (non-condensing)

Parts List
NEBS Tested Parts List
  Part Number Qty Description
CPU P4X-CLX6240-SRF8X 2 Cascade lake 6240 Processors
Memory MEM-DR480L-HL05-ER26
MEM-DR480L-HL01-ER29
MEM-DR432L-CL01-ER29
MEM-DR464L-SL01-ER29
- 8GB - DDR4 – 2666 Hynix
8GB - DDR4 – 2933 Hynix
32GB - DDR4 – 2933 Micron
64GB – DDR4 – 2933 Samsung
Hard Drives HDS-M2T-MTFDDAK480TDN1AT - Micron 5200 – 480GB
HDS-M2T-MTFDDAK480TDT1AW - Micron 5300 Max – 480GB
HDS-S2T1-MZ7LH7T6HMLA05 - Samsung – 7.68TB
HDS-X2T-XA960ME10063 - Seagate – 960GB
HDS-I2T0-SSDSC2KG038T8 - Intel – 3.84TB
GPUs GPU-NVTV100-16
GPU-NVTV100-32
GPU-NVTV100S-32
- Tesla V100 16GB
Tesla V100 32GB
Tesla V100S 32GB
Add on Cards AOC-STG-I4S-P - Standard LP 4-port 10G SFP+
Software SFT-DCMS-Single
DataCenter Management Package (per node license) consists of:
  • OOB Management package capabilities provided by SFT-OOB-LIC
  • Centralized Management Console licenses for health monitoring, power management and firmware upgrades
  • RESTful API support to integrate server management into existing management infrastructure (roadmap Q1’15)
  • Advanced Power Management licenses to manage power on heterogeneous server vendor products
  • Remote Software installation support
  • Remote debug assistance directly from product engineers

Software tools: SSM, SPM, SUM',ABOVE,ol_width=750,ol_border=1,ol_cellpad=6);">SFT-DCMS-Single
- Supermicro System Managment Software license,HF,RoHS/REACH,PBF
