AS -1015A-MT

Key Applications

  • Web/Hosting Application
  • Email/Firewall/Application Server
  • Designed for small and medium businesses

Key Features

  1. AMD Ryzen™ 7000 Series LGA1718 up to 170W TDP Processors
  2. 4x DDR5 UDIMM Slots, ECC/Non-ECC DDR5-5200 Up to total 128GB
  3. 1x PCIe 5.0 x16 (FHHL) slot
  4. 2x 1GbE LAN (Intel® I210-AT)
    IPMI 2.0 + KVM with Dedicated LAN (1GbE)
  5. 500W High-Efficiency Power Supply Platinum Level Certified
Specifications
Product SKUs
A+ Server AS -1015A-MT (Silver)
Motherboard
Super H13SAE-MF
Processor
CPU
  • Single processor(s)
  • AMD Ryzen™ 7000 Series Processors
Core Count
  • Up to 16C/32T
Note
  • Supports 60W - 170W TDP CPUs (Air Cooled)
GPU
Max GPU Count
  • Up to 1 single-width GPU(s)
Supported GPU
System Memory
Memory
  • Memory Capacity: 4 DIMM slots
  • Up to 128GB: 4x 32 GB DRAM
  • Memory Type: 5200/4800/3600MHz ECC DDR5 UDIMM
Memory Voltage
  • 1.1 V
Error Detection
  • ECC/Non-ECC
On-Board Devices
Chipset
  • AMD B650
Network Connectivity
  • 1x 1GbE BaseT with Realtek RTL8211F PHY (dedicated IPMI)
  • 2x 1GbE BaseT with Intel® I210-AT
Input / Output
SATA
  • 4 SATA (6Gbps) port(s)
USB
  • 6 USB port(s) (1 rear; 2 rear; 3 rear)
Video
  • 1 VGA port(s)
  • 1 HDMI port(s)
  • 1 DisplayPort (s)
Serial Port
  • 1 COM Port(s) (1 rear)
TPM
  • TPM header
System BIOS
BIOS Type
  • AMI 32MB SPI Flash
Security
Hardware
  • Trusted Platform Module (TPM) 2.0
PC Health Monitoring
Voltage
  • +1.0V PCH, +1.8V PCH, +12V, +3.3V, +5V, +5V standby, 1.05 (PCH), 3.3V standby, 5 (4-pin), CPU, CPU temperature, CPU thermal trip support, PCH temperature, System temperature, VBAT, VRM
FAN
  • Status monitor for speed control
Temperature
  • CPU thermal trip support, Monitoring for CPU and chassis environment, PECI
Other Features
  • 8-pin 12v DC power connector, ACPI power management, ATX Power connector, Chassis intrusion header, Control of power-on for recovery from AC power loss, CPU thermal trip support for processor
Parts List
