CSE-813MF2TQC-505CB

Key Features


  • High Storage Capacity with Full Height Expansion Slot
  1. 4U chassis support for SMCI Proprietary WIO motherboards; max. motherboard size - 12" x 13", 13" x 13.68"
    * Support up to 12"x13" MB with rear 2.5" HDD option installed
  2. 36 x 3.5" hot-swap drive bay, optional 2 x 2.5" hot-swap drive bay
  3. 12-port 2U SAS3 12Gbps dual-expander backplane, support up to 12x 3.5-inch SAS3/SATA3 HDD/SSD (secondary expander port only connects to dual-port SAS devices, single-port SATA will not have this redundancy feature)
    24-port 4U SAS3 12Gbps dual-expander backplane, support up to 24x 3.5-inch SAS3/SATA3 HDD/SSD (secondary expander port only connects to dual-port SAS devices, single-port SATA will not have this redundancy feature)
  4. 1U 1200W/1000W Titanium Power Supply W/PMbus W76xL336xH40mm
  5. WIO Slots (4x Full-height, Full-length + 3x Low-profile)
  6. 7 x 8cm (7000 RPM) hot-swap PWM cooling fan(s)
Specifications
Product SKUs
CSE-847BE2C-R1K23WB
  • SuperChassis 847BE2C-R1K23WB

Form Factor
  • 4U chassis support for SMCI Proprietary WIO motherboards; max. motherboard size - 12" x 13", 13" x 13.68"
    * Support up to 12"x13" MB with rear 2.5" HDD option installed

Processor Support
  • Dual and Single Intel® and AMD processors

Dimensions
Height
  • 7“ (178 mm)
Width
  • 17.2“ (437 mm)
Depth
  • 27.5“ (699 mm)
Gross Weight
  • 91 lbs (41.28 kg)
Packaging (W x H x L)
  • 27.2“ (691 mm) x 17.4“ (442 mm) x 39.6“ (1006 mm)
Available Color
  • Black

Expansion Slots
  • WIO Slots 3x Low-profile expansion slot(s)
  • WIO Slots 4x Full-height, Full-length expansion slot(s)

Drive Bays
  • Optional 2x 2.5" hot-swap drive bay
  • 36x 3.5" hot-swap drive bay

Backplane
  • 12-Port 2U SAS3 12Gbps dual-expander backplane, support up to 12x 3.5-inch SAS3/SATA3 HDD/SSD (secondary expander port only connects to dual-port SAS devices, single-port SATA will not have this redundancy feature)
  • 24-Port 4U SAS3 12Gbps dual-expander backplane, support up to 24x 3.5-inch SAS3/SATA3 HDD/SSD (secondary expander port only connects to dual-port SAS devices, single-port SATA will not have this redundancy feature)

Peripheral Drives
  • Optional 4x 2.5" internal fixed drive bay
  • Optional 2x 3.5" internal fixed drive bay

Front Panel
Button
  • Power On/Off button
  • System Reset button
LED
  • Power status LED
  • HDD activity LED
  • 2 Network Activity LEDs
  • Unit Identification (UID) LED
  • Fan Fail/System Over Heat LED
Systems Cooling
Fans
  • 7x 8cm (7000 RPM) hot-swap PWM cooling fan(s)

System Monitoring
  • Chassis intrusion switch

Operating Environment (System)
Operating Temperature Range
  • 5°C - 35°C (41°F - 95°F)
Non-Operating Temperature Range
  • -40°C - 70°C (-40°F - 158°F)
Operating Relative Humidity Range
  • 8% - 90% (non-condensing)
Non Operating Relative Humidity Range
  • 5% - 95% (non-condensing)

Power Supply
1U 1200W/1000W Titanium Power Supply W/PMbus W76xL336xH40mm
Power Efficiency
  • 96%
Total Output Power and Input
  • 1200W with Input 200 - 240Vac
  • 1000W with Input 100 - 127Vac
  • 1200W with Input 200 - 240Vdc
AC Input Frequency
  • 50-60Hz
Dimensions (L x W x H)
  • 336 x 76 x 40 mm
Output Type
  • Backplanes (gold finger)
+12V
  • Max: 100A / Min: 0A (200Vdc - 240Vdc)
  • Max: 100A / Min: 0A (200Vac - 240Vac)
  • Max: 83A / Min: 0A (100Vac - 127Vac)
+5Vsb
  • Max: 4A / Min: 0A
Power Distributor
  • PDB-PT847-8824
  • O/P: 12V/135
  • +5V Max: 100A
  • +3.3V Max: 30A
  • -12V Max: 0.6A
Certification
  •   Titanium Certified

Regulatory (Power Supply)
Power Supply Safety / EMC
  • BSMI
  • CCC
  • CE/EMC
  • FCC class A
  • UL/CB
  • UL/CUL
Parts List
Standard Parts List
  Part Number Qty Description
Air Shroud MCP-310-49004-0N 1 SC847/417 DP X9 universal PC air shroud 1368x13/12x13MB
HD Backplane BPN-SAS3-826EL2 1 12-port 2U SAS3 12Gbps dual-expander backplane, support up to 12x 3.5-inch SAS3/SATA3 HDD/SSD (secondary expander port only connects to dual-port SAS devices, single-port SATA will not have this redundancy feature)
HD Backplane BPN-SAS3-846EL2 1 24-port 4U SAS3 12Gbps dual-expander backplane, support up to 24x 3.5-inch SAS3/SATA3 HDD/SSD (secondary expander port only connects to dual-port SAS devices, single-port SATA will not have this redundancy feature)
Cable(s) CBL-0071L 1 ROUND 16 TO 16 PIN RIBBON FP CABLE 30"L, LF
Cable(s) CBL-0160L 2 US POWER CORD 16AWG, PB FREE
Cable(s) CBL-0217L 1 16PIN CNTL PANEL CONVERTER CBL FOR SC826,PBF
Part(s) MCP-230-84705-0N 1 Top cover for SC847 847B series
Part(s) MCP-290-00095-0N 1 4U Chassis Intrusion Assembly 80cm
Part(s) MCP-290-82606-0N 1 SC826 HDD Backplane Bracket
Part(s) MCP-290-84603-0N 1 SC846 HDD Backplane Bracket
Part(s) MCP-290-84607-0V 1 Silver chassis handle set for SC846, 848
Fan(s) FAN-0126L4 7 80x80x38 mm 7K RPM Chassis Middle Fan w/ Housing
Fan(s) FAN-0204L4 7 80x80x38 mm, 7K RPM, Middle Cooling Fan w/ New Plastic Mater
Front Panel MCP-280-82601-0N 1 Front control board adapter (TB826) for SC216,826,936,846
Drive Tray(s) MCP-220-00075-0B 36 Black gen 5.5 hot-swap 3.5“ HDD tray
Drive Tray(s) MCP-220-84709-ASM 1 SC847B WIO MB Tray assembly,HF,RoHS/REACH
Power Distributor PDB-PT847-8824 1 24pin standard output with 5V high current 100Amp power distributor board for SC847
Power Supply & Accessory PWS-1K23A-1R 2 AC-DC 1200W, Titanium Level, Redundancy, 1U, PMBUS 1.2, +12V/+5Vsb, 336x76x40 mm,HF,RoHS/REACH
Mounting Rail(s) MCP-290-00057-0N 1 set Rail set, quick/quick, default for 4U 17.2“ W
Mounting Rail(s) MCP-410-00007-0N 1 Rail screw bag
Optional Parts List
  Part Number Qty Description
Cable CBL-SAST-0532 • - Internal Mini-SAS HD to Mini-SAS HD 50cm,30AWG,12Gb/s
CBL-SAST-0531 • - Internal Mini-SAS HD to Mini-SAS HD 80cm,30AWG,12Gb/s, HF,RoHS/REACH,PBF
Drive Trays MCP-220-84701-0N - Internal drive bay for one 3.5" HDD or two 2.5" HDD
Front Bezel MCP-210-84601-0B • - Front Bezel Cover, Black with Key Lock
Hard Drive Carrier MCP-220-00116-0B • - Black gen-5 3.5-to-2.5 NVMe drive tray, Orange tab (for hotswap NVMe drive),RoHS/REACH
HDD Kit MCP-220-82609-0N - Rear 2.5 x 2 Hot swap HDD kit for 216B/826B/417B/846X/847B
MCP-220-82616-0N • - 12G 2.5x2 Drive Kit w/ Status LED (216B/826B/417B/846X/847B
HDD Tray Converter MCP-220-00043-0N • - 3.5" convert to 2.5" hot-swap HDD Tray
Mounting Rail MCP-290-00058-0N • - 19" to 26.6" rail set, Quick Release, Tool-less
Rail MCP-290-00061-0N • - Non-threaded rail adapter optional for round thread rack
